Name: HIGH RATE DISCHARGE VRLA BATTERY(HR Series)
SKU: 4
Rating: 5 (1003 reviews)

FEATURES AND BENEFITS

30% increased power output at 15 minutes backup time
12 years design life at floating condition @ 20 °C
Optimized plate achieve low internal resistance
Wide operating temperature range from -15°C to 60°C
Low self-discharge rate and long shelf life (1 year at 25°C)
Excellent deep discharge recovery capability

CONSTRUCTION

Positive plate Special designed grid with Pb-Ca-Sn alloy
Negative plate - Balanced Pb-Ca grid for improved recombination efficiency
Separator - Low internal resistance AGM separator
Electrolyte - Dilute high purity sulphuric acid
Battery container and cover - ABS
Pillar seal - 100% factory tested, proven two layers epoxy resin seal
Relief valve - Complete with integrated flame arrestor

APPLICATIONS

Alarm Systems
Communication Equipments
Control Equipments
Security Systems
Medical Equipments
UPS systems
Power Tools
Toys
Emergency Power Systems

CODE

Code	Nominal Voltage (V)	Capacity (AH)	Dimension								Weight		Terminal Type
			Length		Width		Height		Total Height		Kg	Lb
			mm	in	mm	in	mm	in	mm	in	Kg	Lb
HR6-24W	6	24W	70	2.76	47	1.85	101	3.98	107	4.21	0.95	2.09	F1
HR6-36W	6	36W	150	5.91	34	1.34	94	3.7	100	3.94	1.4	3.09	F1
HR6-45W	6	45W	98	3.86	56.5	2.22	115	4.53	115	4.53	2.1	4.63	F2
HR6-55W	6	55W	151	5.94	50	1.97	94	3.7	100	3.94	2.2	4.85	F2
HR6-60W	6	60W	151	5.94	50	1.97	94	3.7	100	3.94	2.3	5.07	F2
HR6-370W	6	370W	194	7.64	170	6.69	207	8.15	210	8.27	16	35.3	T19
HR12L-21W	12	21W	140	5.51	48	1.89	101.5	4	103.5	4.07	1.7	3.75	F1,F2
HR12-24W	12	24W	151	5.94	51	2	93	3.66	99	3.9	1.9	4.19	F1
HR12L-24W	12	24W	140	5.51	48	1.89	101.5	4	103.5	4.07	1.83	4.04	F1,F2
HR12B-24W	12	24W	90	3.54	70	2.76	101	3.98	107	4.21	1.85	4.08	F1
HR12-36W	12	36W	151	5.94	65	2.56	95	3.74	101	3.98	2.7	5.95	F2
HR12-43W	12	43W	151	5.94	65	2.56	111	4.37	117	4.61	3	6.62	F1
HR12-55W	12	55W	151	5.94	98	3.86	95	3.74	101	3.98	4	8.82	F2
HR12-60W	12	60W	151	5.94	98	3.86	95	3.74	101	3.98	4.15	9.15	F2
HR12-75W	12	75W	181	7.13	76	2.99	167	6.57	167	6.57	5.8	12.8	T5
HR12-88W	12	88W	181	7.13	76	2.99	167	6.57	167	6.57	6.2	13.7	T5
HR12-95W	12	95W	181	7.13	76	2.99	167	6.57	167	6.57	6.75	14.9	T5
HR12-100W	12	100W	175	6.89	166	6.54	125	4.92	125	4.92	8.9	19.6	T5
HR12-140W	12	140W	195	7.68	130	5.12	159	6.26	183	7.2	11.2	24.5	T7
HR12-180W	12	180W	197	7.76	165	6.5	170	6.69	170	6.69	14.5	32	T17
HR12-200W	12	200W	230	9.04	138	5.44	209	8.23	213	8.39	17	37.5	T17
HR12-235W	12	235W	350	13.8	166	6.54	176	6.93	176	6.93	21.8	48.1	T17
HR12-270W	12	270W	258	10.2	168	6.62	208	8.19	212	8.35	25	55.1	T17
HR12-310W	12	310W	305	12	168	6.62	208	8.19	212	8.35	27.3	60.2	T17
HR12-370W	12	370W	330	13	172	6.77	215	8.46	221	8.7	30	66.2	T17
HR12-390W	12	390W	330	13	172	6.77	215	8.46	221	8.7	30.5	67.3	T17
HR12-445W	12	445W	406	16	174	6.85	208	8.19	233	9.17	37.5	82.7	T19
HR12-500W	12	500W	341	13.4	172	6.77	284	11.2	288	11.3	45.3	99.9	T19
