Motive Dubhe SI Series

Long Lifespan & Intelligentize & Long Service
Environmentally Friendly & Low Self-Discharge & High Security

Long Lifespan:1C charging and discharging 100% DODcycle life 4000 times,Design ife of 15 years;
Intelligentize:Equipped with DTu module to supportcloud platform management;
Long Service:5 years standard warranty,extendable;
Environmentally Friendly:No pollutant discharge;
Low Self-Discharge:Monthlyself-consumption <2%;
High Security:Using LFP cell,the electrochemical structure is stable,High safety, no fire, no explo-sion.The system is configured with over.charge,overdischarge,andovermildshort-circuit protection,And a fire module toensure zero safety risk.

Application

SI series is suitable for large and medium-sized sightseeing vehicles, patrol vehicles, low-speed logistics vehicles and other large and medium-sized low-speed vehicles;

Specifications

Model	Voltage (V)	Capacity(Ah)	Constant current (A)	Dimension (WLH)	Weight(Kg)	IP Level	Bluetooth	RS48Display5
Dubhe SI76-150	76.8	150	200	680420230	~98	IP65	Yes	Yes
Dubhe SI76-200	76.8	200	200	475442220	~67.3*2	IP65	Yes	Yes
Dubhe SI76-200L	76.8	200	200	1100290280	~125*2	IP65	Yes	Yes
Dubhe SI76-300	76.8	300	300	860260280	~93*2	IP65	Yes	Yes
Dubhe SI96-400	96	400	400	1100335280	~150*2	IP65	DTU	Yes
Dubhe SI96-400L	96	400	400	1450320280	~155*2	IP65	DTU	Yes
Dubhe SI96-560	96	560	400	1360280260	~160*3	IP65	DTU	Yes
Dubhe SI144-200	144	200	200	1200290280	~118*2	IP65	DTU	Yes
Dubhe SI320-105	320	105	105	1200290280	Batt Pack 138	IP65	DTU	Yes
Dubhe SI320-105	320	105	105	500374209	High Box 26	IP65	DTU	Yes
